Duracell battery wrap
Drawing
Layered, prototype drawings of a Mallory Duracell Lithium Battery, LS 501, 1.8/15 Volts. There is a handwritten note in cursive on the top, translucent layer of paper that says "OKed by DD 8/9/72 10:20 AM". There is a blue sticker on the bottom, right-hand corner of a Mallory Organic Lithium Battery wrap, LO-28, 3 Volts. Both the illustration board layer and the top, paper layer have scaled measurements on it.
Typed onto the back of the illustration board in black ink is "139U07".
Made on green-backed, Crescent Illustration Board, Hot Press Surface, No. 200, Heavy Weight.
1997.03.126.03
Donald Dailey Collection
1997.03
Deanne HansenWilliam Dailey
Gift
Donald Dailey
Aug 9, 1972
Drawing, Technical
Projection
Graphic Documents
Documentary Objects
Category 08: Communication Objects
Bottom layer (illustration board)
9-3/4 in
15-1/2 in
Top layer (paper)
8 in
12 in
WhiteBlackBlueSilver
